EXCAVATOR ZX65A
Total Price (including factory option and selected accessory)$0.00
The ZX65A is an excellent hydraulic excavator with an operative weight of 6350 kg (around 6.5 tons) and with a max Digging Depth over 4,1 mt. The machine comes with a 700 mm Standard Bucket, Double Travel Speed and Auxiliary Hydraulic Pipeline (to use for example an Hydraulic Hammer) as standard.
The ZX65A is powered by a reliable and low fuel consumption Kubota V2607 Euro V engine in combination with top notch Hydraulic Components. The Zaox Load Sensing System provide a precise control of different execution elements, good controllability and high working efficiency.
The machine has plenty of power, it is fast, reliable and an enviable quality/price ratio.
Kubota V2607 engine
700mm bucket with teeth
A/C
H/L speed
Auxiliary hydraulic Pipeline
Two year warranty
Price
Sticker Price : $45,190.00
Base Price : $42,750.00 (Discount Applied 10.6039%)
$40,400.00
(Sticker Price : $45,190.00 )
Discount is not applied on Factory Options and Accessories.
All prices are without VAT
Pay in other currency
View Full Configuration
One of our sales manager will contact you by message or telephone to discuss your possible purchase in the next 48 hours.
Performance
EXCAVATOR ZX65A
When digging, the ZX65A feels smooth and precise, with progressive movements that let you “feel” the bucket and boom in every phase. The Load Sensing hydraulic system meters power intelligently—no jerky reactions, no nervous behavior, just clean control even when material conditions change. In repeated dig-and-dump cycles you keep a steady rhythm with fewer corrections. Result: higher productivity, more comfort, and cleaner finishing.
EXCAVATOR ZX65A
The ZX65A has a true excavator design: bigger, taller, and with a presence that instantly communicates strength. The cab is well proportioned and the overall profile stays clean and tidy, with tough lines and a modern look without fluff. With 5940 mm in length and 1880 mm in width, it looks built for serious job sites where stability and credibility matter. Even standing still, it feels powerful and in control.
EXCAVATOR ZX65A
In the ZX65A cab, visibility is a real strong point: you get a clear view forward, to the sides, and especially of the working area, so you can control the bucket and attachment without guessing distances. Large glass surfaces and a higher seating position help you work more precisely near edges, trucks, or obstacles. That means safer moves, fewer corrections, and a faster working rhythm. It’s a cab that makes you feel in control—especially when finishing.
EXCAVATOR ZX65A
The dozer blade on the ZX65A isn’t just an extra—it adds stability while digging and helps keep the machine planted, especially on uneven ground. Plus, you can actually use it like a dozer for quick leveling, backfilling, and finishing without switching machines. It’s ideal for preparing the surface, closing a trench, or cleaning up material at the end of the job. Result: more control, faster work, and a cleaner site.
Machine Specification
| (mm) | Total Length | 5940 |
|---|---|---|
| (mm) | Total Width | 1950 |
| (kg) | Machine Weight (with all fluids) | 6275 |
| (mm) | Cabin Height | 2600 |
| (mm) | Axle Base | 1990 |
| (mm) | Wheel (track) Distance | 1480 |
| (mm) | Minimum Ground Clearance | 353 |
| (mm) | Tail Swing Radius | 1689 |
| (㎡/mm) | Standard Bucket Capacity/Length | 0.21/700 |
|---|---|---|
| (rmp) | Swing Speed | 1-11 |
| (°) | Gradeability | 35 |
| (KN) | Max. Bucket Digging Force | 48 |
| (KN) | Max. Arm Digging Force | 35 |
| Engine Model | KUBOTA V2706 | |
| (Kw(HP)/rpm) | Power/Revolution speed | 42.4[56.8]/2200 |
| (MPa) | System Pressure | 28 |
| (L) | Fuel Tank Capacity | 87 |
| (L) | Hydraulic Circuit Capacity | 100 |
| (L) | Cooling Circuit Capacity | 18 |
| (L) | Engine Oil Capacity | 12 |
| (m³) | Bucket capacity | 0.21 |
| (mm) | Max. Digging Height | 5499 |
|---|---|---|
| (mm) | Max. Dumping Height | 3845 |
| (mm) | Max. Digging Depth | 3808 |
| (mm) | Max. Vertical Digging Depth | 2983 |
| (mm) | Max. Digging Radius | 6128 |
| (mm) | Max. Swing Radius | 2607 |
| (mm) | MAx. Dozer Blade Lifting Distance | 376 |
| (mm) | MAx. Dozer Blade Cutting Distance | 474 |
| Machinery Size | ||
|---|---|---|
| (mm) | Total Length | 5940 |
| (mm) | Total Width | 1950 |
| (kg) | Machine Weight (with all fluids) | 6275 |
| (mm) | Cabin Height | 2600 |
| (mm) | Axle Base | 1990 |
| (mm) | Wheel (track) Distance | 1480 |
| (mm) | Minimum Ground Clearance | 353 |
| (mm) | Tail Swing Radius | 1689 |
| Tech. Specifications | ||
| (㎡/mm) | Standard Bucket Capacity/Length | 0.21/700 |
| (rmp) | Swing Speed | 1-11 |
| (°) | Gradeability | 35 |
| (KN) | Max. Bucket Digging Force | 48 |
| (KN) | Max. Arm Digging Force | 35 |
| Engine Model | KUBOTA V2706 | |
| (Kw(HP)/rpm) | Power/Revolution speed | 42.4[56.8]/2200 |
| (MPa) | System Pressure | 28 |
| (L) | Fuel Tank Capacity | 87 |
| (L) | Hydraulic Circuit Capacity | 100 |
| (L) | Cooling Circuit Capacity | 18 |
| (L) | Engine Oil Capacity | 12 |
| (m³) | Bucket capacity | 0.21 |
| Working Range | ||
| (mm) | Max. Digging Height | 5499 |
| (mm) | Max. Dumping Height | 3845 |
| (mm) | Max. Digging Depth | 3808 |
| (mm) | Max. Vertical Digging Depth | 2983 |
| (mm) | Max. Digging Radius | 6128 |
| (mm) | Max. Swing Radius | 2607 |
| (mm) | MAx. Dozer Blade Lifting Distance | 376 |
| (mm) | MAx. Dozer Blade Cutting Distance | 474 |
