WEIGHT
945 Kg
Engine Model
KUBOTA Z482
Max. Digging Depth
1715
The ZA10 is an inexpensive hydraulic mini excavator with an operative weight of 945 kg (around 1 tons), especially suitable for agricultural work. The machine has a max Digging Depth over 1.7 mt. and it comes with a Standard Bucket large 38 cm and Auxiliary Hydraulic Pipeline (to use for example an Hydraulic Hammer) as standard.
The ZA10A is powered by a reliable and low fuel consumption Kubota Z428 Euro V engine in combination with good Hydraulic Components. The mini excavator's good controllability is guaranteed by a simple lever system that guarantees more than acceptable precision .
The machine has plenty of power and a great quality/price ratio.
Kubota 482 engine
380mm bucket with teeth
Swing boom
Canopy
Rubber Truck
Auxiliary hydraulic Pipeline
Two year warranty
Performance
MINI EXCAVATOR ZA10
The ZA10 is built around a simple, no-nonsense design where practicality comes first—everything is made to work, not to show off. Compact but well-balanced, it stays planted while digging, lifting, and positioning material, even on rough ground. Strong digging force and an intuitive layout make it easy to maneuver and precise to operate, especially for clean trenching and accurate finishing work.
MINI EXCAVATOR ZA10
The ZA10 control layout is simple and operator-friendly: two main hydraulic levers handle the working functions, while the two center levers control travel (translation/walking) for forward/reverse movement and steering. On the right, the switch/indicator panel and ignition are placed within easy reach for quick start-up and basic controls.v
MINI EXCAVATOR ZA10
The ZA10 is built to feel solid on the ground: a stable stance and balanced undercarriage help you work with confidence even on uneven terrain. It delivers strong digging force for its size, while staying easy to maneuver in tight areas. And even with mechanical (non-servo-assisted) controls, the response is smooth and predictable—great sensitivity that makes precise grading and clean trenching feel natural.
MINI EXCAVATOR ZA10
On the ZA10, engine access is extremely simple: just open the hood under the seat and everything is right there. You get easy access to the hydraulic filter and all other filters, the radiator, coolant/water check, engine oil, and diesel refueling — all under the hood for quick, straightforward maintenance.
Media
Machine Specification
| (mm) | Total Length | 2840 |
|---|---|---|
| (mm) | Total Width | 880 |
| (kg) | Machine Weight (with all fluids) | 870 |
| (mm) | Canopy Height | 2220 |
| (mm) | Axle Base | 900 |
| (mm) | Wheel (track) Distance | 660 |
| (mm) | Minimum Ground Clearance | 132 |
| (mm) | Tail Swing Radius | 800 |
| (㎡/mm) | Standard Bucket Capacity/Length | 0.023/380 |
|---|---|---|
| (rmp) | Swing Speed | 0-13 |
| (°) | Gradeability | 30 |
| (KN) | Max. Bucket Digging Force | 7.2 |
| (KN) | Max. Arm Digging Force | 4.6 |
| Engine Model | KUBOTA Z482 | |
| (Kw(HP)/rpm) | Power/Revolution speed | 7(9.3)/3000 |
| (MPa) | System Pressure | 16 |
| (L) | Fuel Tank Capacity | 4 |
| (L) | Hydraulic Circuit Capacity | 10 |
| (L) | Cooling Circuit Capacity | 3 |
| (L) | Engine Oil Capacity | 1.8 |
| (m³) | Bucket capacity | 0.023 |
| (mm) | Max. Digging Height | 2600 |
|---|---|---|
| (mm) | Max. Dumping Height | 1380 |
| (mm) | Max. Digging Depth | 1715 |
| (mm) | Max. Vertical Digging Depth | 1590 |
| (mm) | Max. Digging Radius | 3065 |
| (mm) | Max. Swing Radius | 1480 |
| Machinery Size | ||
|---|---|---|
| (mm) | Total Length | 2840 |
| (mm) | Total Width | 880 |
| (kg) | Machine Weight (with all fluids) | 870 |
| (mm) | Canopy Height | 2220 |
| (mm) | Axle Base | 900 |
| (mm) | Wheel (track) Distance | 660 |
| (mm) | Minimum Ground Clearance | 132 |
| (mm) | Tail Swing Radius | 800 |
| Tech. Specifications | ||
| (㎡/mm) | Standard Bucket Capacity/Length | 0.023/380 |
| (rmp) | Swing Speed | 0-13 |
| (°) | Gradeability | 30 |
| (KN) | Max. Bucket Digging Force | 7.2 |
| (KN) | Max. Arm Digging Force | 4.6 |
| Engine Model | KUBOTA Z482 | |
| (Kw(HP)/rpm) | Power/Revolution speed | 7(9.3)/3000 |
| (MPa) | System Pressure | 16 |
| (L) | Fuel Tank Capacity | 4 |
| (L) | Hydraulic Circuit Capacity | 10 |
| (L) | Cooling Circuit Capacity | 3 |
| (L) | Engine Oil Capacity | 1.8 |
| (m³) | Bucket capacity | 0.023 |
| Working Range | ||
| (mm) | Max. Digging Height | 2600 |
| (mm) | Max. Dumping Height | 1380 |
| (mm) | Max. Digging Depth | 1715 |
| (mm) | Max. Vertical Digging Depth | 1590 |
| (mm) | Max. Digging Radius | 3065 |
| (mm) | Max. Swing Radius | 1480 |
| Machinery Size | ||
|---|---|---|
| Total Length | ||
| (mm) | 2840 | |
| Total Width | ||
| (mm) | 880 | |
| Machine Weight (with all fluids) | ||
| (kg) | 870 | |
| Canopy Height | ||
| (mm) | 2220 | |
| Axle Base | ||
| (mm) | 900 | |
| Wheel (track) Distance | ||
| (mm) | 660 | |
| Minimum Ground Clearance | ||
| (mm) | 132 | |
| Tail Swing Radius | ||
| (mm) | 800 | |
| Tech. Specifications | ||
| Standard Bucket Capacity/Length | ||
| (㎡/mm) | 0.023/380 | |
| Swing Speed | ||
| (rmp) | 0-13 | |
| Gradeability | ||
| (°) | 30 | |
| Max. Bucket Digging Force | ||
| (KN) | 7.2 | |
| Max. Arm Digging Force | ||
| (KN) | 4.6 | |
| Engine Model | ||
| KUBOTA Z482 | ||
| Power/Revolution speed | ||
| (Kw(HP)/rpm) | 7(9.3)/3000 | |
| System Pressure | ||
| (MPa) | 16 | |
| Fuel Tank Capacity | ||
| (L) | 4 | |
| Hydraulic Circuit Capacity | ||
| (L) | 10 | |
| Cooling Circuit Capacity | ||
| (L) | 3 | |
| Engine Oil Capacity | ||
| (L) | 1.8 | |
| Bucket capacity | ||
| (m³) | 0.023 | |
| Working Range | ||
| Max. Digging Height | ||
| (mm) | 2600 | |
| Max. Dumping Height | ||
| (mm) | 1380 | |
| Max. Digging Depth | ||
| (mm) | 1715 | |
| Max. Vertical Digging Depth | ||
| (mm) | 1590 | |
| Max. Digging Radius | ||
| (mm) | 3065 | |
| Max. Swing Radius | ||
| (mm) | 1480 | |
